한국전통건축에서 보이던 들창이 인도에서 재현되어 있기에 퍼왔다. 콘크리트 덩어리들의 느낌은 그리 썩 좋지 않으나, 땅속에 뿌리 박힌 암석과도 같은 표현과 들창의 리듬감이 적절히 대비가 되며 조화를 이루는 모습으로 보인다.
Photographer Edmund Sumner has shared with us his photos of this house that cost just $12,000 to build by Matharoo Associates in Ahmadabad, India, featuring shutters weighted with concrete balls. Update: this project is included in Dezeen Book of Ideas, which is on sale now for £12.
Called The House with Balls, the building was designed for the owner of an aquarium shop and houses four huge tanks for breeding fish.
It also doubles as a weekend retreat.
The long narrow main room is lined on both sides by shutters, opening on one side to the garden and over the tanks on the other.
The concrete balls dip into the water on the tank side when the shutters are opened.
The project has been awarded the AR House 2010 award.
All photographs are copyright Edmund Sumner.
More about Edmund Sumner’s photographs on Dezeen:
New Architecture in Japan (March 2010)
The Delhi Art Gallery by Morphogenesis (December 2009)
Pearl Academy of Fashion by Morphogenesis (September 2009)
Takasugi-an by Terunobu Fujimori (March 2009)
Yakisugi House by Terunobu Fujimori (March 2009)
Colour Factory by Dan Brill Architects (February 2009)
Outside the Box (June 2008)
Kait Workshop by Junya Ishigami Architects (May 2008)
Gravesend public toilets by Plastik Architects (January 2008)
Boiler Suit by Thomas Heatherwick (August 2007)
Here’s some more information about the building, written by Rhys Williams:
Ahmadabad India
Matharoo Associates
THE $100 per SQM HOUSE WITH BALLS
Scooped out of a plot of farmland twenty minutes outside Ahmedabad city, this house has been built for an aquarium shop owner to function as a place to breed fish as well as to serve as a weekend retreat.
Its design is centred around four fish breeding tanks and an observation room which could double up as a living room.
Every aspect of this design is set out to strip expense from the project; be it using 125mm thin concrete walls with standard concrete, one duct space for its three bathrooms, doors and windows made by pressing GI sheets or using bent rods to function as a handle and locking aldrop.
On approaching the entry from the country lane one finds the entrance nondescript and hidden in the scrub.
The mandatory margin required is used for the tank space – while the walls of the plot and house are used as a retention structure for the tanks.
These tanks are enclosed by glass windows which runs the entire length of the living space, the added bonus being that the glass works out cheaper than a concrete wall, more so for aquarium manufacturers!
On entering the house one steps up into a corridor opening to a small powder room on the left, followed by a choice to either take the left into the bedroom, or to carry on down directly into the long living space.
The layout of the house is such that several differing views of the water bodies are provided; in the bedroom space, the sitting ledge is just above the water level and looks down the long length of the pools; while the living space affords the inhabitant an uninterrupted view over the tanks when the windows are open, and view of the fish through below-the-sill glass windows.
Resting half-sunken under the ground level, negating the need for foundations, the long concrete-box house splits the plot space into two distinct yet continuously mingling spaces; it opens on one side to the garden and to the four nine thousand litre fish breeding tanks on the other.
The living area can be opened to either of these two spaces by top hung metal shutters which extend at eye level through the entire length of the walls.
When closed it is a 13m long and 3.6m wide space rendered by the light through the fish tanks. On opening the shutters this linear space transforms completely into an infinite one perpendicular to its original direction.
The metal shutters are held by handmade concrete baubles, the cheapest counterweights possible; they either swing in the wind when windows are partially open or dip out of view into the lily padded pools when the windows are fully open making the house animated in use or even without.
The concrete frame around the window plays multiple roles; as a seat from the garden side, steps for children to climb on from the garden or jump to from the terrace, a weather protection device while also providing a rat & snake proof section.
It starts serving as a bar counter with the attached kitchen platform for larger gatherings. The grassy knoll that rises in front of the long opening bears under it a bio-gas plant, fifty thousand litres of rain water storage, and an earth heat exchange tube.
Click above for larger image
Back through the shrubbery and fields the house assumes a squat position; the curving wall to one side allows one to walk up a gentle slope on to the terrace running over the length of the house. The weekenders enjoy the feeling of floating over a bed of lily petals while being weighed down by the baubles.
Click above for larger image
Project title HOUSE WITH BALLS
Location Ahmedabad, Gujarat, India
Design year(s): 2003
Construction year(s): 2004
Architects Matharoo Associates
Principal(s) in charge: Gurjit Singh Matharoo
Project team: Gurjit Singh Matharoo- principal architect, Hardik
Pandit – trainee
Client(s): Mr. Mahesh Mohatta
Consultants:
Structural engineer(s) Mr. Rajendra Singh Matharoo
Interior designer(s): Matharoo Associates
Landscape architect(s): Matharoo Associates
Others: -
General contractor: Shriram Builders, Ahmedabad
Program: Living room, bedroom, caretaker’s room, 4 fish
breeding tanks, kitchen, 3 toilets, 1 parking.
Structural system: Concrete Raft and Walls
Major materials: Reinforced Cement Concrete
Site area: Approx. 530 m2
Building area: Approx. 130 m2
Total floor area: Approx. 130 m2
Cost of construction: Approx. $100/m2 – $12,000 (in 2004)
